2.壓輥、烘道自動恒溫控制。
3.上膠輥、刮膠輥精度高，涂膠均勻。
4.可以做水性膠、油性膠、無膠膜、預涂膜等多種功能為一體

Features:

1.The machine adopts Cast-iron structure, Sophisticated manufacturing process, long service life.

2.Pressure rolls, bake Road, automatic constant temperature control

3.The gluing rolls and the glue spreading rolle are high precision, uniform coating

4.multi-function:water-based glue, oily glue, non-glue film, precoating film and so on.

SDFM110B高精度多功能覆膜機設計先進,結構緊湊.使用方便.工作壓力大.升溫快,噪音低,運轉平穩,變頻調速等特點。該機對深色印刷品復膜而出現的雪花點.斑霧等現象的弊端.減少了產品的損耗率.提高產品的檔次,進而大大提高了工作效率.是現代印刷包裝行業不可缺少的印后加工設備.
該機以BOPP膜為材料可廣泛應用于包裝盒,食品盒,書刊,圖紙,證件等制品的單面復膜,經復膜后的印刷品,防水,經久耐用,立體感強..

SDFM High-precision multi-functionlaminating machinewith advanced design, compact structure and convenience of using, high work pressure, fast of heating, low noise, smooth operation, VVVF. which have avoided snowflakes points and fog spots, reduced the loss rate of Products, thus improved work efficiency. In conclusion,multi-functionlaminating machinelaminating machine is indispensable to modern post-printing industry.

The machine is made of thermal BOPP film material, can be widely used for boxes, food boxes, books, drawings, documents, etc. After post-laminating, the products will be waterproof, durable, andStereoscopic.

主要技術參數（main technical parameters）：

型號規格(Model)： SDFM-1100B SDFM-1000B SDFM-800B

復膜寬度(Width of laminating)： 1050mm 950mm 800mm

復膜速度(Speed of laminating)： 0-38m/min 0-38m/min 0-38m/min

壓合壓力（Pressure of laminating）： 0-25MPa 0-25MPa 0-25MPa

復膜溫度(Temperature of laminating )：30-120℃30-120℃30-120℃

總功率(Total Power)： 40KW 40KW 40KW

整機重量(Weight of Machine)： 3.4T 3.2T 3T

外形尺寸（Overall Dimensions）:6300*1720*2600 6300*1620*2600 6300*1500*2600
